OIL LUBRICATED rotary vane Vacuum pumps
The technology of lubricated vacuum pumps is perfectly suited to both the medium vacuum of industrial applications and the finer vacuum reserved for research applications. Lubricated pumps are designed with one or two stages. The final pressure range depends on the variants of the different series.
Rotary with lubricated vanes
EM – Monobloc lubricated single-stage pumps
EM 4-8
Limit pressure : ≤ 2 and ≤ 20 mbar
Pumping speed : 4÷10 m 3 /h
EM 12-20
Limit pressure : ≤ 2 and ≤ 20 mbar
Pumping speed : 12÷21 m3/h
EM 28-40
Limit pressure : ≤ 2 and ≤ 20 mbar
Pumping speed : 28÷51 m 3 /h
EU NEXT GENERATION - Single stage lubricated pumps
EU 47/67
Limit pressure: ≤ 0.1 mbar ≤ 0.8 mbar (HWT)
Pumping speed: 50÷80 m 3 /h
EU/PVL – Lubricated single-stage pumps
EU 45-65-105
Limit pressure: ≤ 0.5 and ≤ 10 mbar
Pumping speed: 48÷126 m 3 /h
EU 160-205-300
Limit pressure: ≤ 0.5 and ≤ 10 mbar
Pumping speed: 152÷360 m 3 /h
EU 650-1000
Limit pressure: ≤ 0.5 and ≤ 10 mbar
Pumping speed: 660÷1239 m 3 /h
PVL 15-35
Limit pressure: ≤ 0.5 and ≤ 20 mbar
Pumping speed: 17÷42 m 3 /h
PVL 401-541
Limit pressure: ≤ 0.5 and ≤ 10 mbar
Pumping speed: 417÷663 m 3 /h
EU H – High vacuum lubricated single-stage pumps
EU 107H-300H-650H
Limit pressure: ≤ 0.1 mbar
Pumping speed: 110÷790 m 3 /h
EU HWT – High Water Tolerance lubricated single-stage pumps
EU HWT series with high vapor disposal capacity
Limit pressure: ≤ 0.8 mbar
Pumping speed: 50÷790 m 3 /h
EU EX – ATEX lubricated single-stage pumps
Ex Series
Limit pressure: ≤ 0.5 mbar
Pumping speed: 48÷1033 m 3 /h
EU OX – Lubricated single-stage pumps for O 2 treatment
Ox series
Limit pressure: ≤ 0.5 mbar
Pumping speed: 18÷1239 m 3 /h
Special lubricated single-stage pumps
EU 300W - PVL 541W - EU 650W Cooled with passing water
Limit pressure: ≤ 0.5 and ≤ 10 mbar
Pumping speed: 553÷790 m 3 /h
Rotary with lubricated vanes
PHV K – Double stage pumps
PHV 5K-10K-20K-30K
Limit pressure: ≤ 7 x 10 -4 mbar
Pumping speed: 5÷36 m 3 /h
PHV 50K-75K
Limit pressure: ≤ 7 x 10 -4 mbar
Pumping speed: 50÷90 m 3 /h
